Technical Specifications Overview Dimensions
130 x 151.4 x 302.9 mm (5.1 x 6 x 11.9") IR Night Vision
15 m (50 ft) Zoom Mode
3x Optical License Plate Recognition
Yes Smart Detections (People, Vehicles, Animals)
Yes Resolution
4K Field of View
Wide: H 109.9°, V 60°, D 127.7° Tele: H 35°, V 19.8°, D 40° Audio
Microphone Weatherproofing
IP66 Tamper Resistance
IK04 Mounting
Wall, ceiling, pole mount (Included) Junction box, angled base (Optional) UniFi Application Suite
Protect Performance Networking Interface
GbE RJ45 port Video Image Settings
Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay Max. Frame Rate
30 FPS Resolution
8MP 3840 x 2160 (16:9) Optics Sensor
1/1.8" 8MP Lens
F 4.1–12.3 mm; ƒ/1.53–ƒ/3.3 IR Capture Distance
15 m (50 ft) LPR Night Mode
LPR optimization filter Hardware Max. Power Consumption
25.5W Supported Voltage Range
42.5–57V DC Power Method
PoE+ Processor
Quad-core Arm® Cortex®-A53 based chip Pole Mount Diameter
1.5–2" (38–50 mm) Weight
1.5 kg (3.3 lb) Enclosure Material
Aluminum alloy, polycarbonate Mount Material
Aluminum Alloy Expansion Slot
Micro SD memory card Button
(1) Factory reset Cable Cable Connector Type
RJ45 Cable Diameter
4.5 mm (0.2") Cable Length
30 cm (1 ft) Jacket Material
Thermoplastic elastomer Jacket Enclosure Dimensions
⌀20 x 70.6 mm (0.8 x 2.8") Jacket Enclosure Material
Thermoplastic elastomer, polycarbonate, silicone rubber Ambient Operating Temperature
-20 to 50° C (-4 to 122° F) Ambient Operating Humidity
10 to 90% noncondensing NDAA Compliant
Yes Certifications
CE, FCC, IC
